No inventory for distributors
Because everything is made to order, a distributor does not have to hold stock.
Ask for a price on a common specOrdering and delivery
Made to your spec. Shipped in a median of 31 days
There are no standard items and no stock. Every sleeve is built for one press, measured, and shipped.
Made to order
31 days
Median ship time, export orders
Made to order
How ordering works
- 01
Send the dimensions
Sleeve ID (mandrel OD), face length, print repeat or wall thickness, quantity, and the press model if you know it. A photo of the current sleeve end and notch helps.
- 02
We confirm the model and quote
Wall thickness determines the model. We confirm the spec, the antistatic option and the price for the quantity.
- 03
Production on your mould
Mandrel moulds cover 70.144–490.063 mm, with multiple sets held in-house. Label-width sizes can be produced several per mould.
- 04
Measured, then shipped
Every sleeve is measured for OD, straightness, runout and dynamic balance before packing. Export orders ship in a median of 31 days from confirmed order.
Ordering and delivery
Full size range
OD 63–575 mm, repeat 200–1800 mm, length 300–3000 mm, wall 1–100 mm.
Full specification rangeNon-standard sizes
Odd mandrel diameters and long faces are quoted the same way as common sizes. Send the numbers.
Send dimensionsProduct matrix
Specification range
- Outer diameter
- 63 – 575 mm
- Print repeat
- 200 – 1800 mm
- Sleeve length
- 300 – 3000 mm
- Wall thickness (per side)
- 1 – 100 mm
- Mandrel mould coverage
- 70.144 – 490.063 mm
- Surface
- Epoxy resin system, Shore D82 (X-MUT: D90)
- Antistatic option
- Rg < 1×10⁶ Ω
Shipped tolerances, measured on every sleeve
±0.02 mm
Outer diameter
≤ 0.015 mm
Straightness
≤ 0.02 mm
Runout
G2.5
Dynamic balance
Four numbers a press OEM or a technical buyer can re-check at incoming inspection
Sleeve dimensions
Send us your mandrel dimensions
Send us the sleeve ID (mandrel OD), the face length and the print repeat you need. The wall thickness follows from those, and the model follows from the wall thickness.
01Send the dimensions
- Sleeve ID (mandrel OD)
- face length
- print repeat or wall thickness
- quantity
- the press model if you know it
A photo of the current sleeve end and notch helps.
Ready to send a spec?
Use the form, or email the dimensions directly.
